GZHA MINI FOUR
GZHA MINI FOUR
4-channel class D compact amplifier
640 Watts
4-channel amplifier with high efficient class D circuit, integrated activ crossover and compact dimensions
- Compact sized 4-channel amplifier
- SMD components
- Class D technology
- Variable active crossover and bass boost, phase shift
- Stabilized power supply
- Large terminals
- Solid heatsink with engraved Ground Zero lettering
- High-level input with auto-on function
| Model | Class D compact amplifier |
|---|---|
| Channels | 4 |
| Output Power (@ 4Ω) | 4x 80Watts RMS |
| Output Power (@ 2Ω) | 4x 130 Watts RMS |
| max. Output Power (CEA-2006A / 10%THD+N) | 640 Watts |
| Frequency Response | 5 Hz – 38 kHz |
| HPF / LPF / BPF | ● / ● / ● |
| Bass Boost / Phasenregelung | ○ / ○ |
| High-Level Input / Auto-on | ● / ● |
| Remote Control | ○ |
| BIAS Setting | ○ |
| Linkmode | ○ |
| Dimensions (b x l x h) | 135 x 210 x 52 mm |
GZHA MINI ONE-K
GZHA MINI ONE-K
1-channel class D compact amplifier
1200 Watts
1-channel subwoofer amplifier with high efficient class D circuit, integrated activ crossover and compact dimensions
- Compact sized mono amplifier
- SMD components
- Class D technology
- Variable active crossover and bass boost, phase shift
- Link mode (for two amplifiers)
- Stabilized power supply
- Large terminals
- Solid heatsink with engraved Ground Zero lettering
- Bass remote control included
- High-level input with auto-on function
| Model | Class D compact amplifier |
|---|---|
| Channels | 1 |
| Output Power (@ 4Ω) | 340 Watts RMS |
| Output Power (@ 2Ω) | 600 Watts RMS |
| Output Power (@ 1Ω) | 1000 Watts RMS |
| max. Output Power (CEA-2006A / 10%THD+N) | 1200 Watts |
| Frequency Response | 10 – 200 Hz |
| HPF / LPF / BPF | ● / ● / ● |
| Bass Boost / Phasenregelung | ● / ● |
| High-Level Input / Auto-on | ● / ● |
| Remote Control | ● |
| BIAS Setting | ○ |
| Linkmode | ● |
| Dimensions (b x l x h) | 135 x 322 x 52 mm |
GZDSP 4-8XII
GZDSP 4-8XII
8-channel digital signal processor
8-channel DSP
Digital signal processor with four channel high-level or RCA input, USB connection, optional remote control and auto-on function
- 8-channel digital signal processor
- High-level and line input
- Realtime setting
- 2x 28 bit Analog Devices Prozessor
- Windows GUI software
- Separate 10 band equalizer for each channel
- Time delay
- Variable crossover
- Phase correction
- Automatic turn-on function
| Model | 8-channel digital signal processor |
|---|---|
| High Resolution Compatibel | no |
| TOSLINK Input | no |
| AUX Connector | no |
| High-Level Audio Mix | up to 4 channels |
| Frequency Response | 10 Hz – 22 kHz (-3dB) |
| Signal-to-Noise | > 105 dB |
| Input Sensitivity | 0.5 – 1 V (RCA), 2 – 8 V (high-level) |
| Max. Output | 2.5 V RMS |
| Adapter for Apple® devices | no |
| Remote | optional |
| Preset Memory | 6 |
| Dimensions (W x L x H) | 168 x 114 x 27 mm / 6.61 x 4.49 x 1.06" |
